USB to Zigbee Wireless Gateway/Module/Converter(BUE-ZIG-USB)
Detail description:
BUE series of USB to Zigbee wireless serial communication device, using the Zigbee wireless technical, is compliance with the industrial standard. It has advantages of long communication distance, strong anti-jamming, flexible network to make sure transparent data transmission among many devices with self-organizing star, line and mesh network topology.
Performance:
Long communication distance: maximum 1500m at sight
Strong anti-jamming function: 2.4DSSS
Flexible serial application: transparent format or instruction format, maximal baud rate 115200
Flexible node type: coordinator node, router node or end device (optional)
Strong network function: star, tree, line, mesh
Big network capacity: 16channels for choosing, 65535 network ID to be set
Technical parameter
Wireless Protocol: Zigbee2007/PRO
Wireless frequency: 2400-2485m 2.4 ISM free frequency range
Channel: 16channels
Channel detection: CSMA/CA
Antenna rate: 250K stable
Networking construction: star, line, tree, mesh
Network capacity: 65535
Transmission type: broadcast or target address to send
Input voltage: DC5V
Average power consumption:0.6W
Transmit power output: 25dbm
Baud rate: bit rate 1200-115200 optional
Standard accessories: 3dBi glue stick antenna, data wire and the USB driver.
Optional accessories: suction cup antenna with extended cable
Work Temperature: -20-70C
