10/100M Ethernet to Fiber Optic Converter
The HFB Series 10/100M Auto-Sensing Ethernet Fiber Optic Transceiver is designed using advanced fiber optic technology. This series transmit and receive 10/100 Mbps (no adjustment is required) data over two single-mode optical fibers, extending the Ethernet transmission distance from its normal few hundred meters to 0-120 kilometers. By using optical fiber as transmission media, this series continue to perform its secured, high-speed and long-distance communication even under the adverse condition such as lighting, power surge and electromagnetic interference; Substantial saving on lighting and power surge protection equipments if copper wires were used.
The HFB Series is fully assembled using SMT components for stability and reliability.
ETHERNET |
|
Supporting standards |
IEEE802.3 10Base-T, 100Base-T |
Data Rate |
10/100Mbps auto-sensing, Full Duplex or Half Duplex |
Physical Interface |
RJ45, DCE interface |
OPTICAL |
|
Number of Fibers |
2 |
Wavelength |
1310nm or 850nm |
Fiber Type |
9/125μ m(SM) |
Distance |
0 ~ 25km, 0~40km, 0~60km, 0-80km |
Connector Type |
ST/FC/SC |
GENERAL |
|
Operating Temperature |
-40 ~ 70C / -40 ~ +158F |
Relative Humidity |
0 ~ 95% non-condensing |
Mean Time Between Failure (MTBF) |
> 600, 000hrs |
Power Supply Adaptors |
AC 220V 110v or DC+110V, +5V, +12V, +24V, +48V Option |
Enclosure Color |
Silver |
Dimensions ( L× W× H ) |
25(L)× 110(W)× 36(H)Wall Mount & DIN Rail |
Ordering information:
Model Number |
Description |
Fiber No. |
Fiber Mode |
Fiber Connector |
HFB-FO-100M-P1M |
Point to point Link,Single Fiber(BI-DI), 2km |
1 |
Multi Mode |
ST/SC/FC |
HFB-FO-100M-P2M |
Point to point Link,Dual Fiber, 2km |
2 |
Multi Mode |
ST/SC/FC |
HFB-FO-100M-P1S |
Point to point Link,Single Fiber(BI-DI), 20km |
1 |
Single Mode |
ST/SC/FC |
HFB-FO-100M-P2S |
Point to point Link,Dual Fiber, 20km |
2 |
Single Mode |
ST/SC/FC |
