4 Port Configurable CAN FD Fiber Optic Switch(Router)

Description:

The CAN-FD-FIB-MIXED Can bus to fiber optic switch provide an optical point-to-point or bus network connection for Can FD data interfaces on one or two, multimode or single mode optical fibers. The CAN FD fiber optic switch has 2 CAN ports and 2 fiber optic ports, all 4 ports are configurable via software.Any port can communicate with other ports,so it has the functions of “Repeater”,”Router” and “Switch”, it can be used  in point to point,multi drop bus,star and tree topologies.

The CAN-FD-FIB-MIXED can be used in CAN (FD) network with baud rate up to 5 Mbps. It can be used in various high-level CAN (FD) protocols (CANopen, SDS, J1939, DeviceNet or other customized protocols).

The CAN-FD-FIB-MIXED can be configured with corresponding CAN (FD) message filter to ensure that only the required data is transmitted to other CAN (FD) networks through the repeater. Therefore, the device can effectively reduce the network load.

Product Features and Benefits:

  • 32-bit 400Mb high-speed processor, embedded with real-time operating system and adaptive flow control algorithm, suitable for the system with strict real-time requirements.
  • The port has queue buffering to ensure the frame integrity of all applications from low speed to high speed.
  • The port uses rotary dial switch to set the baud rate of CAN (FD) data. For most applications, customers even do not need to use configuration software.
  • The port has indicator for sending, receiving and status indication, which is convenient for industrial field debugging.
  • The configuration software and configuration method of CAN (FD) to serial port, CAN (FD) bridge, CAN (FD) switch, CAN (FD) to optical (point-to-point), CAN (FD) to optical (bus type), CAN (FD) fiber optic switch are completely unified. Customers can switch between these products seamlessly.
  • The CAN FD port can process 5000 frames per second.
  • The CAN (FD) interface has electrical isolation, and the isolation voltage is 2500V DC
  • It has 2-channel fiber interfaces (transmission distance 10-15km, 25km / 40km / 60km optional), ST / SC / FC interfaces as option.
  • Users can configure communication baud rate: 5Kbps ~ 5Mbps through rotary button or RS232 port
  • Powerful CAN (FD) message filtering function,which can effectively avoid unnecessary messages being forwarded
  • Built in terminal resistor and external termination resistor are optional.
  • Power supply, device status, bus transmitting, bus receiving, bus error LED indicators.
  • Wide voltage range: 9-40V DC (surge, over-current, reverse connection protection)

Specifications:

Data

Data Formats

CAN FD, CAN OPEN,Device Net

CAN Data Rate

5Kbps~5Mbps

Bit Error Rate

<1 x 10-12

Connectors

Data

Screw Block Terminal 2 ports

Fiber

ST, SC or FC (ST fitted as standard)

Environmental

Operating Temperature

-30C---+70C

Storage Temperature

-40C---+85C

Operating Humidity

0-95%

MTBF

>100,000 Hours

Optical

Fiber

Multi mode or single mode

Wavelength

MM:850/1310nm,SM:1310/1550nm

Number of fibers

4 or 2(WDM,Bi-Di)  (2TX+2RX)

Power

Power Input

+9-+40V DC

Mechanical

Dimensions

147(W)×112(D)×46(H)mm Wall mount





Ordering Information:

Model Number

Description

Fiber No.

Fiber Mode

Fiber Connector

HFD-FO-FD-P1M

Point to Point Link,Single Fiber(BI-DI), 2km, DIN Rail mount

1

Multi Mode

ST/SC/FC

HFD-FO-FD-P2M

Point to Point Link,Dual Fiber, 2km, DIN Rail mount

2

Multi Mode

ST/SC/FC

HFD-FO-FD-P1S

Point to Point Link,Single Fiber(BI-DI), 20km, DIN Rail mount

1

Single Mode

ST/SC/FC

HFD-FO-FD-P2S

Point to Point Link,Dual Fiber, 20km, DIN Rail mount

2

Single Mode

ST/SC/FC

CAN-FD-FIB-100PT-P1M

Point to Point Link,Single Fiber(BI-DI), 2km, Wall or rack mount

1

Multi Mode

ST/SC/FC

CAN-FD-FIB-100PT-P2M

Point to Point Link,Dual Fiber, 2km, Wall or rack mount

2

Multi Mode

ST/SC/FC

CAN-FD-FIB-100PT-P1S

Point to Point Link,Single Fiber(BI-DI), 20km, Wall or rack mount

1

Single Mode

ST/SC/FC

CAN-FD-FIB-100PT-P2S

Point to Point Link,Dual Fiber, 20km, Wall or rack mount

2

Single Mode

ST/SC/FC

CAN-FD-100BT-M2M

Multi-drop Link,Dual Fiber(BI-DI), 2km

2

Multi Mode

ST/SC/FC

CAN-FD-100BT-M4M

Multi-drop  Link,4 Fiber, 2km

4

Multi Mode

ST/SC/FC

CAN-FD-100BT-M2S

Multi-drop Link,Dual Fiber(BI-DI), 20km

2

Single Mode

ST/SC/FC

CAN-FD-100BT-M4S

Multi-drop Link,4 Fiber, 20km

4

Single Mode

ST/SC/FC

CAN-FD-FIB-MIXED-P1M

CANFD Fiber Optic Switch, 2 CAN+2 Fiber

2

Multi Mode

ST/SC/FC

CANFD-FIB-MIXED-P2M

CANFD Fiber Optic Switch, 2 CAN+4 Fiber

4

Multi Mode

ST/SC/FC

CANFD-FIB-MIXED-P1S

CANFD Fiber Optic Switch, 2 CAN+2 Fiber

2

Single Mode

ST/SC/FC

CANFD-FIB-MIXED-P2S

CANFD Fiber Optic Switch, 2 CAN+4 Fiber

4

Single Mode

ST/SC/FC

CANFD-Bridge-200T

CAN FD to CAN Bus Bridge

N/A

N/A

N/A

CANFD-SW-400T

CAN FD Switch

N/A

N/A

N/A

CANFD-COM-100T

CAN FD to RS-232/485/422 Converter

N/A

N/A

N/A

CANFD-USB-100T

CAN FD to USB Converter, 1 channel

N/A

N/A

N/A

CANFD-USB-200T

 CAN FD to USB Converter, 2 channels

N/A

N/A

N/A

CANFD-NET-100T

CAN FD to Ethernet Converter 1 channel

N/A

N/A

N/A

CANFD-NET-200T

CAN FD to Ethernet Converter 2 channels

N/A

N/A

N/A
